MODEL	HR6010-C	HR6012-C	HR7012-C	HR7013-C
Shaped Area(mm)	570x1000	570x1200	670x1200	670X1300
Width of Shaping Die(mm)	500-600	500-600	600-700	600-700
Depth of Shaping(mm)	150	150	150	150
Vacuum Pump	3HP	3HP	3HP	3HP
Air Compressor	5HP	5HP	5HP	5HP
Power	22kw	25kw	28kw	30kw
Size of Machine(mm)	3630x2400x2600	3830x2400x2600	3830x2500x2600	4030x2500x2600
*We can make and design to customer’s order for other specification.

Computerized automatic-controlled multi-settings. Easy adjust. Rapid response in heating up. Stable temperature. All contributes to formal material the most favorable forming temperature and environment.
The advance and retreat of the electric heater is driven by double-hinged motor. No vibration is generated to extend the life expectancy of the machine.
Using DC motor pulling force. The feeding length of material is accurate and fast. Strong pulling force and steady operational movement are able to extend the life expectancy of every part.
The altitude and depth of upper mold and lower mold can be adjusted automatically. Cold spray moves in a back-and-forward mode.
Three types of off-mold mode:(1)Continuous puff (2) Intermittent puff(3) mold-vibrating puff can be applied for any difficult tasks and products.
Using alloy electro-heating tube for heating to prevent the deformation of heating tube. Therefore, the life expectancy of the heating tube is twice longer than regular stainless tube.
Controlled by computer-human interface, it can memorized up to 180 different sets of conditions, like temperature, time, numbers and various parameters etc., for mold forming.

MODEL	HR 6010-C	HR 6012-C	HR 7012-C
Shaped Area(mm)	570 X1000	570 x1200	670 x1200
Width of Shaping Die(mm)	500-600	500-600	600-700
Depth of Shaping(mm)	150	150	150
Vacuum Pump	3HP	3HP	3HP
Air Compressor	5HP	5HP	5HP
Power	22kw	25kw	28kw
Size of Machine(mm)	3630x2400x2600	3830x2400x2600	3830x2500x2600
*We can make and design to customer’s order for other specification.

Computerized automatic-controlled multi-settings. Easy adjust. Rapid response in heating up. Stable temperature. All contributes to formal material the most favorable forming temperature and environment.
Operation of the electric heater is steady and produces no vibration; in times of electrical outage the heater returns to its original position maintaining a high degree of safety.
Using motor pulling force. The feeding length of material is accurate and fast. Strong pulling force and steady operational movement are able to extend the life expectancy of every part.
Three types of off-mold mode:(1)Continuous puff (2) Intermittent puff(3) mold-vibrating puff can be applied for any difficult tasks and products.
